Who to contact for buying Bentley 3500/22?
3500/22 usually refers to the Transient Data Interface (TDI) module in the 3500 series vibration detection system produced by Bentley Company, with the model number 3500/22. The following is the content of the instruction manual compiled based on relevant materials:
Function Overview: The 3500 Transient Data Interface (TDI) is a combination of the 3500 Monitoring System and Bentley Nevada System1 ™ The interface between mechanical management software. It combines the functionality of the 3500/20 Framework Interface Module (RIM) and communication processors such as TDXnet.
Working principle: TDI is used in conjunction with M-series monitors (such as 3500/40M, 3500/42M, etc.) to receive input signals from eddy current sensors or electromagnetic sensors, continuously collect steady-state and transient waveform data, and transmit the data to the main computer software through Ethernet.
Main features: TDI has standard static data acquisition function, using optional channel enabled disks, and can also collect transient or dynamic data. For Triple Modular Redundancy (TMR) applications, the 3500 system requires TDI in TMR form. In addition to the functions of standard TDI, TMR TDI also has a "monitor channel comparison function" that can continuously compare the outputs of three redundant monitors.
Installation requirements: TDI runs in the RIM slot of the 3500 framework, occupying only one slot in the framework, located in the first slot (adjacent to the power module).
Technical parameters: The input signal range is -0.8V to -21.0V for non insulated I/O modules and+5V to -11V for insulated I/O modules.
Meaning of front panel indicator lights: Although the document does not explicitly mention the 3500/22 front panel indicator lights, reference can be made to similar series such as 3500/40M. Usually, the OK LED indicator module is operating normally, and the TX/RX LED indicator module is communicating with other modules within the 3500 frame. The 3500/22 may have indicator lights with similar meanings used to display the working status.
4 pieces of information
If you need to purchase Bentley 3500/22 transient data interface module, it is recommended to contact Guizhou Yuanmiao Automation Equipment. As a core component of the 3500 series, this module can efficiently connect the vibration monitoring system with System1 ™ Software that accurately collects steady-state and transient waveform data, adapts to triple module redundant applications, and ensures stable operation of industrial equipment.
Guizhou Yuanmiao is deeply engaged in the field of automation, supplying genuine Bentley products and providing professional and reliable services. Contact person Ye Ye, phone 15339537795, email 342289566@qq.com We are always available to provide you with quotation consultation and procurement support, helping to efficiently build equipment monitoring systems.
