ABB 5SHX2645L0004 3BHL000389P0104
ABB 5SHX2645L0004 is a high-voltage IGBT module produced by ABB, and 3BHL000389P0104 is ABB's industrial control module 1. Here are their product specifications:
5SHX2645L00041：
Application areas: Used for high voltage and high power scenarios such as high voltage direct current transmission (HVDC), flexible alternating current transmission systems (FACTS), industrial drives, and electric traction.
Voltage level: up to 6.5kV.
Current capacity: Supports continuous currents ranging from hundreds to thousands of amperes.
Switching frequency: up to tens of kilohertz (kHz).
Packaging form: High voltage modular packaging, built-in water-cooled or air-cooled cooling system.
Control interface: compatible with fiber optic or electrically isolated drive signals.
Protection function: Built in over temperature, over current, and short circuit protection.
3BHL000389P01041：
Application areas: Used in the field of industrial automation, suitable for process control, data acquisition and monitoring systems (SCADA), etc.
Channel quantity: Provides multi-channel analog input/output, the specific quantity depends on the model.
Signal type: Supports voltage (such as ± 10V), current (such as 4-20mA), thermistor (RTD), thermocouple (TC), etc.
Resolution: up to 16 bits or higher.
Sampling rate: configurable.
Communication interface: Supports mainstream industrial bus protocols such as PROFIBUS, Modbus, EtherNet/IP, etc.
Isolation protection: Electrical isolation between channels and between channels and power supply.
In addition, there is information showing that 3BHL000389P0104 is a fully controllable solid-state switch based on IGCT technology, which can be used for the long pulse klystron modulator 2 of linear particle beam accelerators. The relevant parameters are as follows 2:
Charging voltage: 4.4kV.
Maximum peak voltage: 9.0kV.
Rated shutdown current: 1850A.
Maximum shutdown current: 3700A.
Pulse width (typical): 2ms.
Pulse width (maximum): 2.3ms.
Pulse repetition frequency: 2Hz.
Maximum stray inductance: 3 µ H.
Environmental temperature range: 5 ℃ -40 ℃.
Cooling method: convective air.
